NORCO Faze 3
2010 Faze 3
Looking for small parts and frame assembly documents? Visit our help centre

Specs
All
Frame
FAZE 3, 100-120 mm adj travel , M6 tubing
Fork
Tora XC Coil 120 mm travel
Rear Shock
Rockshox Bar 2.1 air shock
Headset
FSA TH-855 threadless
Grips
Norco Sheild dual density
Handle Bar
Norco Alloy 20 mm rise bar
Stem
Norco XC alloy MTB stem
Seat Post
Norco double bolt seatpost clamp
Saddle
WTB Rocket V comp
Front Brake
Avid Juicy 3 6" front
Rear Brake
Avid Juicy 3
Brake Levers
Avid Juicy 3
Shifter Front
Shimano Deore Rapid Fire 9 speed
Shifter Rear
Shimano Deore Rapid Fire 9 speed
Front Derailleur
Shimano Deore
Rear Derailleur
Shimano Deore
Cassette
Shimano Deare HG-50 9 speed
Chain
KMC Z-9000
Crankset
Shimano Deore 442 crank
Bottom Bracket
Shimano UN-26 square BB
Chain Tensioner
N/A
Pedals
Shimano PD M-505
Front Hub
Shimano M-475
Rear Hub
Shimano M-475
Spokes
Shadar spokes
Rims
Alex DC 25
Tires
Kenda Small Block 8 26 x 2.10
Tubes
N/A
Geometry
Frame Weight
XSN/A
SN/A
MN/A
LN/A
XLN/A
Bike Weight
XSN/A
SN/A
M31.5 lbs(14.2 kgs)
LN/A
XLN/A
Front Travel
XS101
SN/A
MN/A
LN/A
XLN/A
Rear Travel
XS120
SN/A
MN/A
LN/A
XLN/A
Seat Tube C-T
XS381
S393
M432
L470
XL508
Head Angle
XS69.5
S70
M70
L70
XL70
Seat Angle
XS73
S73
M73.5
L73.5
XL73.5
Horizontal Top Tube Length
XS545
S565
M585
L605
XL630
Top Tube Length C-C
XS528
S545
M562
L582
XL608
Head Tube Length
XS105
S105
M115
L130
XL145
Fork Length
XS491
S491
M491
L491
XL491
Bottom Bracket Height
XS339
S339
M339
L339
XL339
Stand Over Height
XS740
S750
M768
L791
XL815
Wheel Base
XS1054
S1069
M1090
L1111
XL1137
Front Centre
XS628
S643
M664
L685
XL711
Rear Centre
XS426
S426
M426
L426
XL426
