Item number: 181044
-
Description:
Cam rotor pumps are also called Colloid pump, rotor pumps, cam pumps, three-lobe pumps, etc.Cam rotor pumps are widely used in beer,food, dairy, beverage, chemical, pharmaceutical and other industries.

Parameter:
Model ZB3A
Voltage 220V
Phase Three-phase power
Flow 300-800L/h
Power 0.55K
Maximum speed limit 500r/min
Recommended speed 100-400r/min


Introduction:
1.Used to transfer high viscosity liquids in various industrial fields:Foodstuff: molasses, honey, yoghourt, chocolate, tomato sauce, syrup, fruit juice, cooking oil, edible oil, vegetable oil, cheese, protein, ketchup, sesame paste, mashed garlic, peanut butter, chilli sauce, etc.Cosmetics: facial cleanser, shampoo, toothpaste, lotions, creams, liquid soap, shower gel, hairspray, etc.
Others: medicine, fertilizer solution, ceramic glaze, paint coating, etc.
2.Made of by stainless steel 304 which conformed to the sanitray standard

Working principle:
The cam rotor pump sucking the materials through two synchronously rotating rotors to generate suction at the inlet of the rotating process.The two rotors divide the rotor chamber into several spaces and follow the order of a-b-c-d.

Product Characteristics:
1.High viscosity delivery: The characteristics of low speed, high output torque and high temperature resistance make the rotor pump stand out in the field of conveying high viscosity and high temperature materials. and the conveying viscosity can be as high as 1000000CP.

2.Food grade stainless steel: All parts in contact with the material are made of stainless steel that meets hygienic standards.And be used in all sanitary and corrosion resistant applications in the food, beverage, medical, chemical and other industries.

3.Mechanical seal and easy to clean:The mechanical sealing mechanism with flushing function prevents the normal operation of the material from being condensed on the end face of the mechanical seal during the process of conveying the high-viscosity material. And can guarantee the service life of mechanical seals in sinister environments.

3.No wearing parts:The rotor pump does not wear any parts during operation. All parts in contact with the material are made of stainless steel. A pair of rotors operate synchronously during operation, maintaining a certain gap between each other. No contact is produced and there is no theoretical wear and tear.

Industry use:
Used to transfer high viscosity liquids in various industrial fields:
Foodstuff: molasses, honey, yoghourt, chocolate, tomato sauce, syrup, fruit juice, cooking oil, edible oil, vegetable oil, cheese, protein, ketchup, sesame paste, mashed garlic, peanut butter, chilli sauce, etc.
Cosmetics: facial cleanser, shampoo, toothpaste, lotions, creams, liquid soap, shower gel, hairspray, etc.
Others: medicine, fertilizer solution, ceramic glaze, paint coating, etc.


If you need other model pls contact with us.

Item Included: 181044
1*Hygienic grade cam rotor pump(181044)


Notice
1.Limited stock, please purchase ASAP if you want it.
2.Before pickup, please call us to make sure.
3.The price will be adjusted when there's large fluctuations in exchange rates and raw material costs.
4.Advertising price does not include the tax.
