Item number # 170740
1.[Loading Capacity]: Horizontal loading capacity: 30 KG/66 LB; Vertical loading capacity:15KG/33 LB. Working table diameter/height: 310mm/380mm. Made of stainless steel, features high quality and durablility. Thickness of working table: 12mm.
2.[0-90º Rotary Table]- The turning structure of worm and gear has the function of self-lock, and the worktable can be turned steplessly between 0-90°. Working table also can be fixed at any angle you want.
3.[3-Jaw Lathe Chuck]- 3 jaws are reinforced to prevent the weldment pieces from moving and falling.It is upgraded to be more accurate and more practical. Holding diameter range: 10-340mm/4-13.3in.
4.[Stepless Speed Control]- Using foot switch to control table rotation, the speed is regulated by the knob on the machine(0.5-5r/min stepless speed regulation).
5.[Time Control]- Time-controller can be furnished to control the working condition and working time, which can achieve the linkage of the positioner and welder.
-
Parameter:
Voltage:110v
Table Capacity Vertical Load: 33lbs(15kg)
Tilt Range: 0-90
Table Diameter: 12.2''(310mm)
Table Capacity Horizontal Load: 66lbs(30kg)
Weight: 77lbs(35kg)
Table Center Bore: 1''(25mm)
The Rotation Speed: 1-15rpm
Size: 14*15*15''(360*380*380mm)
-
Feature
1.Two ways to control the table, by foot switch and automaticaly.
2.The tile range of rotary table is 0-90, work can set the shaft, so the welding at arbitrary angle can be achieved.
3.Special design of anti-electromagnetic, which reduce the high frequency interference of TIG'S welding, at the same time can improve the welding quality effectively.
4.A time-controller can be furnished to control the working condition and working time, which can achieve the linkage of the positioner and welder.
5.The adjustable-welding gun support can be furnished to fix the position of the welding torch.
-
Item Included(170740)
welding Positioner*1
Holder*1
Chuck*1
Foot Switch*1

Notice
1.Limited stock, please purchase ASAP if you want it.
2.Before pickup, please call us to make sure.
3.The price will be adjusted when there's large fluctuations in exchange rates and raw material costs.
4.Advertising price does not include the tax.
-
